Small Sealed Marking Machine With Fiber Laser Source

laser marking machine

Product Description

Small sealed marking machine with fiber laser source can be used for marking logo, serial number, bar code and other beautiful patterns on any metallic materials such as stainless steel, titanium, brass, gold, silver, aluminum and lots of engineering plastic products suchas mobile cover & charger, consume electronics housing and etc.
Our laser marking machine adopts the best quality fiber laser source in the world, And on the outside of the marking machine with acrylic cover, to avoid laser damage to the human eyes.We have 10w, 20w, 30w and 50w for optional. The estimated life for laser source will be around 100,000hours.

Laser power

20W/30W/50W/60W/1000W
Laser wavelength355±1nm
Beam quality<1.2
Laser repetition frequency10KHZ ~ 50KHZ
Min tuning Q laser pulse width30ns
Beam divergence angle<0.3mrad
Standard marking range110*110mm
Optional engraving range150* 150mm/200*200mm
Engraving depth≤0.5mm
Share on facebook
Facebook
Share on twitter
Twitter
Share on linkedin
LinkedIn
Share on whatsapp
WhatsApp
Share on email
Email

Small Sealed Marking Machine With Fiber Laser Source Advantages

1. Can process a variety of metal materials.Especially for high hardness, high melting point, brittle materials marking more advantages.

2, belongs to non-contact processing, no damage to the product, no tool wear, good quality marking.

3. The laser beam is thin, the processing material consumption is small, and the processing heat affected zone is small.

4, High processing efficiency, computer control, easy to achieve automation.

Small Sealed Marking Machine With Fiber Laser Source Product Parameter

Laser power20W/30W/50W/60W/1000W
Laser wavelength355±1nm
Beam quality<1.2
Laser repetition frequency10KHZ ~ 50KHZ
Min tuning Q laser pulse width30ns
Beam divergence angle<0.3mrad
Standard marking range110*110mm
Optional engraving range150* 150mm/200*200mm
Engraving depth≤0.5mm
Engraving linear speed12000mm/s
Min. line width0.01mm
Repetition accuracy±0.003mm
Marking formatGraphics, text, bar code, 2D code, date, shift number, batch number, serial number, document link (support the graphic import of any design software)
Operating systemWINXP Chinese operating interface, support PLT, PCX, DXF, BMP, and other file formats, adopt SHX, TTF fonts
Power consumption≤3KW
Electrical connection220V±22V/50HZ/15A
Laser unitUV
Working temperature15~30ºC (no dust and required air-conditioner)
Relative humidity<80%

Small Sealed Marking Machine With Fiber Laser Source Machine Parts

laser marking machine

Small Sealed Marking Machine With Fiber Laser Source Marking Samples

Applicable Industries of fiber laser marking machine:

Mobile Phone keypad,plastic translucent keys,electronics components,integrated

circuits (IC),electrical appliances,communications products,sanitary ware,tools,

accessories,knives,eyeglasses and clocks,jewelry,auto parts,luggage buckle,cooking

itensiles,stainless steel products and other industries.



Applicable Materials of fiber laser marking machine:

Metal(including rare metals),engineering plastics,electroplating materials,coating

material,plastic,rubber,epoxy resin,ceramic,plastic,ABS,PVC,PES,steel,copper and

other materials .

raycus 50w fiber laser marking samples

Packing And Shipping

1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.

2.All the spare parts of the machine were covered by some soft materials,mainly using pearl

wool.

Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding waterproof and

rust proof.

3.The outmost is wooden case with fixed formwork.

4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
